Chapter 8. Appendix
194
● System Parameters [88]
Parameters affecting the entire unit, such as how the two MIDI IN connectors will function, are called System Parameters.
<MODEL ID = 42H>
Address(H) Size(H) Data(H) Parameter Description Default(H) Description
00 00 7F 00 00 01 00 - 01 SYSTEM MODE SET [88] 00 MODE1
00: MODE-1 (Single module mode)
01: MODE-2 (Double module mode)
(Rx. only)
* Refer to "System exclusive messages related to Mode settings" (page 191).
CHANNEL MSG RX PORT [88]
00 01 00 00 00 01 00 - 01 BLOCK00 PORT A - B 00 PORT A
::: : :
00 01 0F 00 00 01 00 - 01 BLOCK0F PORT A - B 00 PORT A
00 01 10 00 00 01 00 - 01 BLOCK10 PORT A - B 01 PORT B
::: : :
00 01 1F 00 00 01 00 - 01 BLOCK1F PORT A - B 01 PORT B
* You can modify the receiving MIDI port at which channel messages will be received for each BLOCK. We suggest that normally you use PORT A for BLOCK01-0F, and
PORT B for BLOCK10-1F. (In this case there is no need to change the setting.)
* Refer to page 196 for details of each BLOCK.
● Patch parameters
❍ Patch common parameters
In MODE-1 (Single module mode) this unit functions as a single sound source module with 32 Parts. In MODE-2 (Double module mode) it functions as two sound source mod-
ules with 16 Parts each. The parameters common to all Parts in each module are called Patch Common parameters.
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Descrip-tion
40 00 00 00 00 04 0018 - 07E8 MASTER TUNE -100.0 - +100.0 [cent] 00 04 00 00 0 [cent]
40 00 01# Use nibblized data.
40 00 02#
40 00 03#
* Refer to section 5. Supplementary material, "About tuning" (page 208).
40 00 04 00 00 01 00 - 7F MASTER VOLUME 0 - 127 7F 127
(= F0 7F 7F 04 01 00 vv F7 )
40 00 05 00 00 01 28 - 58 MASTER KEY-SHIFT -24 - +24 [semitones] 40 0[semitones]
40 00 06 00 00 01 01 - 7F MASTER PAN -63 (LEFT) - +63 (RIGHT) 40 0 (CENTER)
40 00 7F 00 00 01 00 MODE SET 00 = GS Reset
(Rx. only)
* Refer to "System exclusive messages related to Mode settings" (page 191).
40 01 00 00 00 10 20 - 7F PATCH NAME 16 ASCII Characters
40 01 : #
40 01 0F#
40 01 30 00 00 01 00 - 07 REVERB MACRO 00: Room 1 04 Hall 2
01: Room 2
02: Room 3
03: Hall 1
04: Hall 2
05: Plate
06: Delay
07: Panning Delay
40 01 31 00 00 01 00 - 07 REVERB CHARACTER 0 - 7 04 4
40 01 32 00 00 01 00 - 07 REVERB PRE-LPF 0 - 7 00 0
40 01 33 00 00 01 00 - 7F REVERB LEVEL 0 - 127 40 64
40 01 34 00 00 01 00 - 7F REVERB TIME 0 - 127 40 64
40 01 35 00 00 01 00 - 7F REVERB DELAY FEEDBACK 0 - 127 00 0
40 01 37 00 00 01 00 - 7F REVERB PREDELAY TIME [88] 0 - 127[ms] 00 0
* REVERB MACRO is a macro parameter that allows global setting of reverb parameters. When you select the reverb type with REVERB MACRO, each reverb parameter will
be set to the most suitable value.
* REVERB CHARACTER is a parameter that changes the reverb algorithm. The value of REVERB CHARACTER corresponds to the REVERB MACRO of the same number.
* In MODE-2 (Double module mode), REVERB PREDELAY TIME cannot be used.
