Chapter 8. Appendix
196
Address(H) Size(H) Data(H) Parameter Default Value (H) Description
40 03 00 00 00 02 00 - 7F EFX TYPE [Pro] 00 00 00: Thru
40 03 01#
40 03 03 00 00 01 00 - 7F EFX PARAMETER 1 [Pro]
40 03 04 00 00 01 00 - 7F EFX PARAMETER 2 [Pro]
40 03 05 00 00 01 00 - 7F EFX PARAMETER 3 [Pro]
40 03 06 00 00 01 00 - 7F EFX PARAMETER 4 [Pro]
40 03 07 00 00 01 00 - 7F EFX PARAMETER 5 [Pro]
40 03 08 00 00 01 00 - 7F EFX PARAMETER 6 [Pro]
40 03 09 00 00 01 00 - 7F EFX PARAMETER 7 [Pro]
40 03 0A 00 00 01 00 - 7F EFX PARAMETER 8 [Pro]
40 03 0B 00 00 01 00 - 7F EFX PARAMETER 9 [Pro]
40 03 0C 00 00 01 00 - 7F EFX PARAMETER 10 [Pro]
40 03 0D 00 00 01 00 - 7F EFX PARAMETER 11 [Pro]
40 03 0E 00 00 01 00 - 7F EFX PARAMETER 12 [Pro]
40 03 0F 00 00 01 00 - 7F EFX PARAMETER 13 [Pro]
40 03 10 00 00 01 00 - 7F EFX PARAMETER 14 [Pro]
40 03 11 00 00 01 00 - 7F EFX PARAMETER 15 [Pro]
40 03 12 00 00 01 00 - 7F EFX PARAMETER 16 [Pro]
40 03 13 00 00 01 00 - 7F EFX PARAMETER 17 [Pro]
40 03 14 00 00 01 00 - 7F EFX PARAMETER 18 [Pro]
40 03 15 00 00 01 00 - 7F EFX PARAMETER 19 [Pro]
40 03 16 00 00 01 00 - 7F EFX PARAMETER 20 [Pro]
* Reading EFX TYPE and EFX PARAMETER please refer to page 56, 176
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 03 17 00 00 01 00 - 7F EFX SEND LEVEL TO REVERB [Pro] 0-127 28 40
40 03 18 00 00 01 00 - 7F EFX SEND LEVEL TO CHORUS [Pro] 0-127 00 0
40 03 19 00 00 01 00 - 7F EFX SEND LEVEL TO DELAY [Pro] 0-127 00 0
40 03 1B 00 00 01 00 - 7F EFX CONTROL SOURCE1 [Pro] Off, CC1-95, CAf, Bend 00 Off
40 03 1C 00 00 01 00 - 7F EFX CONTROL DEPTH1 [Pro] -100 - 0 - +100 [%] 40 0 (%)
40 03 1D 00 00 01 00 - 7F EFX CONTROL SOURCE2 [Pro] Off, CC1 - 95, CAf, Bend 00 Off
40 03 1E 00 00 01 00 - 7F EFX CONTROL DEPTH2 [Pro] -100 - 0 - +100 [%] 40 0 (%)
40 03 1F 00 00 01 00 - 7F EFX SEND EQ SWITCH [Pro] OFF/ON 01 ON
* EFX TYPE is a macro parameter which sets various Insertion Effect parameters as a group. When you use EFX TYPE to select an Insertion Effect type, the various effect
parameters will be set to appropriate values.
* In MODE-2 (Double module mode), EFX SEND TO DELAY and EFX SEND EQ SWITCH cannot be used.
* In the case of Mode 2 (Double Module mode), the Insertion effect cannot be used for Parts with a CHANNEL MSG RX PORT (page 194) setting of PORT B.
Patch Part parameters
This unit has 16 Parts in Group A and 16 Parts in Group B. Parameters that can be set individually for each Part are called Patch Part parameters.
If you use exclusive messages to set Patch Part parameters, specify the address by Block number rather than Part Number (normally the same number as the MIDI channel).
The Block number can be specified as one of 16 blocks, from 0(H) to F(H).
To specify a Part of group A, use the Block number corresponding to the Part and specify an address of 40 ** ** via PORT A (normally MIDI IN A).
To specify a Part of group B, use the Block number corresponding to the Part and specify an address of 40 ** ** via PORT B (normally MIDI IN B).
To specify a Part of either group A or B from a single PORT, specify an address of 40 ** ** for group A Parts or an address of 50 ** ** for group B Parts when using PORT A.
Conversely, to specify a Part of either group A or B from PORT B, specify an address of 50 ** ** for group A Parts or an address of 40 ** ** for group B Parts. In other words,
when specifying Parts of the opposite side as the PORT being used, use addresses 50 ** **.
The relation between Part number and Block number is as follows.
x...BLOCK NUMBER (0 - F), Part 1 (default MIDIch = 1) x=1
Part 2 (default MIDIch = 2) x=2
:: :
Part 9 (default MIDIch = 9) x=9
Part10 (default MIDIch =10) x=0
Part11 (default MIDIch =11) x=A
Part12 (default MIDIch =12) x=B
:: :
Part16 (default MIDIch =16) x=F
n... MIDI channel number (0 - F) of the BLOCK.
In the following map, the control numbers of the control changes are indicated as CC#.
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
40 1x 00 00 00 02 00 - 7F TONE NUMBER CC#00 VALUE 0 - 127 00 0
40 1x 01# 00 - 7F P.C. VALUE 1 - 128 00 1
40 1x 02 00 00 01 00 - 10 Rx. CHANNEL 1 - 16, OFF Same as the Part Number
40 1x 03 00 00 01 00 - 01 Rx. PITCH BEND OFF / ON 01 ON
40 1x 04 00 00 01 00 - 01 Rx. CH PRESSURE(CAf) OFF / ON 01 ON
40 1x 05 00 00 01 00 - 01 Rx. PROGRAM CHANGE OFF / ON 01 ON
40 1x 06 00 00 01 00 - 01 Rx. CONTROL CHANGE OFF / ON 01 ON
40 1x 07 00 00 01 00 - 01 Rx. POLY PRESSURE(PAf) OFF / ON 01 ON
40 1x 08 00 00 01 00 - 01 Rx. NOTE MESSAGE OFF / ON 01 ON
40 1x 09 00 00 01 00 - 01 Rx. RPN OFF / ON 01 ON
40 1x 0A 00 00 01 00 - 01 Rx. NRPN OFF / ON 00(01*) OFF(ON*)
* When "General MIDI System On" is received, Rx. NRPN will be set OFF. When "GS Reset" is received, it will be set ON.
