Chapter 8. Appendix
176
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
0 : Thru 00 00
❍ Effects that modify the tone color (filter type)
1 : Stereo-EQ 01 00
Low Freq 200/400 00/01 03
Low Gain -12 - +5 - +12 34 - 4C 04
Hi Freq 4k/8k 00/01 05
Hi Gain -12 - +12 34 - 4C 06
M1 Freq 200 - 1.6k - 6.3k *10 07
M1 Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 08
M1 Gain -12 - +8 - +12 34 - 4C 09
M2 Freq 200 - 1k - 6.3k *10 0A
M2 Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0B
M2 Gain -12 - -8 - +12 34 - 4C 0C
+ Level 0 - 127 00 - 7F 16
2 : Spectrum 01 01
Band 1 -12 - -4 - +12 34 - 4C 03
Band 2 -12 - +1 - +12 34 - 4C 04
Band 3 -12 - +3 - +12 34 - 4C 05
Band 4 -12 - +6 - +12 34 - 4C 06
Band 5 -12 - +2 - +12 34 - 4C 07
Band 6 -12 - -1 - +12 34 - 4C 08
Band 7 -12 - -4 - +12 34 - 4C 09
Band 8 -12 - -5 - +12 34 - 4C 0A
Width 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0B
+ Pan L63 - 0 - R63 00 - 7F 15
# Level 0 - 127 00 - 7F 16
3 : Enhancer 01 02
+ Sens 0 - 64 - 127 00 - 7F 03
# Mix 0 - 127 00 - 7F 04
Low Gain -12 - +3 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
4 : Humanizer 01 03
Drive 0 - 48 - 127 00 - 7F 03
Drive Sw Off/On 00/01 04
+ Vowel a/i/u/e/o 00/01/02/03/04 05
Accel 0 - 15 *14 06
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Pan L63 - 0 - R63 00 - 7F 15
# Level 0 - 127 00 - 7F 16
❍ Effects that distort the sound (distortion type)
5 : Overdrive 01 10
+ Drive 0 - 48 - 127 00 - 7F 03
Amp Type Small/BltIn/2-Stk/3-Stk 00/01/02/03 04
Amp Sw Off/On 00/01 05
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
# Pan L63 - 0 - R63 00 - 7F 15
Level 0 - 96 - 127 00 - 7F 16
6 : Distortion 01 11
+ Drive 0 - 76 - 127 00 - 7F 03
Amp Type Small/BltIn/2-Stk/3-Stk 00/01/02/03 04
Amp Sw Off/On 00/01 05
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - -8 - +12 34 - 4C 14
# Pan L63 - 0 - R63 00 - 7F 15
Level 0 - 84 - 127 00 - 7F 16
❍
Effects that modulate the sound (modulation type)
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
7 : Phaser 01 20
+ Manual 100 - 620 - 8k *12 03
# Rate 0.05 - 0.85 - 10.0 *6 04
Depth 0 - 64 - 127 00 - 7F 05
Reso 0 - 16 - 127 00 - 7F 06
Mix 0 - 127 00 - 7F 07
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 104 - 127 00 - 7F 16
8 : Auto Wah 01 21
Fil Type LPF/BPF 00/01 03
Sens 0 - 127 00 - 7F 04
+ Manual 0 - 68 - 127 00 - 7F 05
Peak 0 - 62 - 127 00 - 7F 06
# Rate 0.05 - 2.05 - 10.0 *6 07
Depth 0 - 72 - 127 00 - 7F 08
Polarity Down/Up 00/01 09
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Pan L63 - 0 - R63 00 - 7F 15
Level 0 - 96 - 127 00 - 7F 16
9 : Rotary 01 22
Low Slow 0.05 - 0.35 - 10.0 *6 03
Low Fast 0.05 - 6.40 - 10.0 *6 04
Low Accl 0 - 3 - 15 *14 05
Low Level 0 - 127 00 - 7F 06
Hi Slow 0.05 - 0.90 - 10.0 *6 07
Hi Fast 0.05 - 7.50 - 10.0 *6 08
Hi Accl 0 - 11 - 15 *14 09
Hi Level 0 - 64 - 127 00 - 7F 0A
Separate 0 - 96 - 127 00 - 7F 0B
+ Speed Slow/Fast 00/7F 0D
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
# Level 0 - 127 00 - 7F 16
10 : Stereo Flanger 01 23
Pre Filter Off/LPF/HPF 00/01/02 03
Cutoff 250 - 8k *9 04
Pre Dly 0 - 1.6m - 100m *1 05
+ Rate 0.05 - 0.60 - 10.0 *6 06
Depth 0 - 24 - 127 00 - 7F 07
# Feedback -98% - +80% - +98% 0F - 71 08
Phase 0 - 180 00 - 5A 09
Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 104 - 127 00 - 7F 16
11 : Step Flanger 01 24
Pre Dly 0 - 1.0m - 100m *1 03
Rate 0.05 - 0.30 - 10.0 *6 04
Depth 0 - 95 - 127 00 - 7F 05
+ Feedback -98% - +30% - +98% 0F - 71 06
Phase 0 - 180 00 - 5A 07
# Step Rate 0.05 - 2.75 - 10.0 *6 08
Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 96 - 127 00 - 7F 16
■ Effect list
+: Effect control 1 can be used to modify the value (p.92)
#: Effect control 2 can be used to modify the value (p.92)
MSB/LSB: Indicates the ** portion of the following exclusive mes-
sages. (p.196) (hexadecimal notation)
For Effect Type (data section)
F0 41 dev 42 12 40 03 00 ** ** sum F7
For Effect Parameters (LSB part of address)
F0 41 dev 42 12 40 03 ** data sum F7
(dev: device ID, sum: checksum)
The correspondence between setting values and hexadeci-
mal values for items in the Value column indicated with "*" is
shown in the "Effect Data Table" (p. 183).
*1 Pre Delay Time *8 HF Damp
*2 Delay Time 1 *9 Cutoff Freq
*3 Delay Time 2 *10 EQ Freq
*4 Delay Time 3 *11 LPF
*5 Delay Time 4 *12 Manual
*6 Rate 1 *13 Azimuth
*7 Rate 2 *14 Accl
