Cutoff (Cutoff frequency) 250 - 8k [2]
Adjust the center frequency of the filter for the cho-
rus sound for the chorus sound.
Pre Dly (Pre delay time) 0 - 100m [3]
Adjust the time delay from when the direct sound
begins until the processed sound is heard.
+Rate 0.05 - 10.0 [4]
Adjust the rate of modulation.
Depth 0 - 127 [5]
Adjust the depth of modulation.
Phase 0 - 180 [7]
Adjust the spatial spread of the sound.
#Balance (Effect balance) D> 0E - D 0<E [16]
Adjust the volume balance between the direct and
the processed sound.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Low Gain -12 - +12 [17]
Adjust the gain of the low frequency range.
Hi Gain (High gain) -12 - +12 [18]
Adjust the gain of the high frequency range.
Level (Output level) 0 - 127 [20]
Adjust the output level.
19: Space D [01H, 43H]
Space-D is a multiple chorus that applies two-phase
modulation in stereo. It gives no impression of modula-
tion, but produces a transparent chorus effect.
Pre Dly (Pre delay time) 0 - 100m [1]
Adjust the time delay from when the direct sound
begins until the processed sound is heard.
+Rate 0.05 - 10.0 [2]
Adjust the rate of modulation.
Depth 0 - 127 [3]
Adjust the depth of modulation.
Phase 0 - 180 [4]
Adjust the spatial spread of the sound.
#Balance (Effect balance) D> 0E - D 0<E [16]
Adjust the volume balance between the direct and
the processed sound.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Low Gain -12 - +12 [17]
Adjust the gain of the low frequency range.
Hi Gain (High gain) -12 - +12 [18]
Adjust the gain of the high frequency range.
Level (Output level) 0 - 127 [20]
Adjust the output level.
20: 3D Chorus [01H, 44H]
This applies a 3D effect to the chorus sound. The cho-
rus sound will be positioned 90 degrees left and 90
degrees right.
Pre Dly (Pre delay time) 0 - 100m [1]
Adjust the time delay from when the direct sound
begins until the processed sound is heard.
+Cho Rate (Chorus Rate) 0.05 - 10.0 [2]
Adjust the modulation speed of the chorus sound.
Cho Depth (Chorus Depth) 0 - 127 [3]
Adjust the modulation depth of the chorus sound.
Out (Output Mode) Speaker/Phones [15]
Specify the method that will be used to hear the
sound which is output to the OUTPUT jacks. The
optimal 3D effect will be achieved if you select
Speaker when using speakers, or Phones when
using headphones (p.91).
#Balance (Effect balance) D> 0E - D 0<E [16]
Adjust the volume balance between the direct and
the processed sound.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Low Gain -12 - +12 [17]
Adjust the gain of the low frequency range.
Hi Gain (High gain) -12 - +12 [18]
Adjust the gain of the high frequency range.
Level (Output level) 0 - 127 [20]
Adjust the output level.
❍ Effects that reverberate the sound
(delay/reverb type)
21: Stereo Delay [01H, 50H]
This is a stereo delay.
L
R
Space D
Balance
EQ
EQ
L
R
3D Chorus
Balance
EQ
EQ
Chapter 4. Insertion Effects
