Chapter 8. Appendix
200
● User instrument
You can modify the parameters of this unit sound to your taste, and save your new settings in Variation numbers 64 or 65 of the Native map / SC-88 map (page 98). A sound
saved in this way is called a User Instrument. You can save 256 different sounds in this way.
The parameters you can set are Vibrato, Filter and Envelope.
b: bank number (0H = GS Variation number 64, 1H = GS Variation number 65)
pp: program number (00 - 7F: 1 - 128)
Address(H) Size(H) Data(H) Parameter Description Default Value (H) Description
20 b0 pp 00 00 01 01 - 03 SOURCE TONE# (MAP) [88] --
20 b1 pp 00 00 01 00 - 7F (CC#00 : Bank number MSB) [88] --
20 b2 pp 00 00 01 00 - 7F (PG# : Program number) [88] --
20 b3 pp 00 00 01 00 - 7F USER INST MODIFY1-2 [88] -64 - +63 40 0
Vibrato Rate
20 b4 pp 00 00 01 00 - 7F USER INST MODIFY2-2 [88] -64 - +63 40 0
Vibrato Depth
20 b5 pp 00 00 01 00 - 7F USER INST MODIFY3-2 [88] -64 - +63 40 0
TVF Cutoff Freq
20 b6 pp 00 00 01 00 - 7F USER INST MODIFY4-2 [88] -64 - +63 40 0
TVF Resonance
20 b7 pp 00 00 01 00 - 7F USER INST MODIFY5-2 [88] -64 - +63 40 0
TVF&TVA Env.attack
20 b8 pp 00 00 01 00 - 7F USER INST MODIFY6-2 [88] -64 - +63 40 0
TVF&TVA Env.decay
20 b9 pp 00 00 01 00 - 7F USER INST MODIFY7-2 [88] -64 - +63 40 0
TVF&TVA Env.release
20 bA pp 00 00 01 00 - 7F USER INST MODIFY8-2 [88] -64 - +63 40 0
Vibrato Delay
● User Drum Set
You can modify drum instrument parameters to your liking, and save this data as a Drum Set. A Drum Set saved in this way is called a User Drum Set. You can save up to two
Drum Sets, and since each set contains 128 instrumental sounds, this provides a total of 256 instrumental sounds (Drum Instruments). You can also give each User Drum Set
a name of your choice. User Drum Sets are stored in Drum Set numbers 65 and 66 of the Native map / SC-88 map.
d: drum set number (0H = User drum set number 65, 1H = User Drum Set number 66)
rr: drum part note number (00 - 7F)
Address(H) Size(H) Data(H) Parameter Description
21 d0 00 00 00 0C 20 - 7F USER DRUM SET NAME [88] 32 - 127
: (ASCII 12 characters)
21 d0 0B#
21 d1 rr 00 00 01 00 - 7F PLAY NOTE [88] 0 - 127
21 d2 rr 00 00 01 00 - 7F LEVEL [88] 0 - 127
21 d3 rr 00 00 01 00 - 7F ASSIGN GROUP [88] 0 - 127
21 d4 rr 00 00 01 00 - 7F PAN [88] 0 - 127
21 d5 rr 00 00 01 00 - 7F REVERB SEND LEVEL [88] 0 - 127
21 d6 rr 00 00 01 00 - 7F CHORUS SEND LEVEL [88] 0 - 127
21 d7 rr 00 00 01 00 - 01 RX NOTE OFF [88] OFF / ON
21 d8 rr 00 00 01 00 - 01 RX NOTE ON [88] OFF / ON
21 d9 rr 00 00 01 00 - 7F DELAY SEND LEVEL [88] 0 - 127
21 dA rr 00 00 01 01 - 03 SOURCE DRUM SET# (MAP) [88] 1 - 3
21 dB rr 00 00 01 00 - 7F (PG#: Program number) [88] 0 - 127
21 dC rr 00 00 01 00 - 7F SOURCE NOTE NUMBER [88] 0 - 127
● User Effect
You can modify the Insertion Effect parameters as desired and store them as an Effect Type. Effect Types that are stored in this way are referred to as User Effects. 64 differ-
ent Effect Types can be stored. These are stored in Effect Type numbers 40 00H through 40 3FH.
pp: LSB number of EFX TYPE (00 - 3F : 0-64)
Address(H) Size(H) Data(H) Parameter
22 00 pp 00 00 02 -- SOURCE EFX TYPE [Pro]
22 01 pp#
22 03 pp 00 00 01 00 - 7F EFX PARAMETER 1 [Pro]
22 04 pp 00 00 01 00 - 7F EFX PARAMETER 2 [Pro]
22 05 pp 00 00 01 00 - 7F EFX PARAMETER 3 [Pro]
22 06 pp 00 00 01 00 - 7F EFX PARAMETER 4 [Pro]
22 07 pp 00 00 01 00 - 7F EFX PARAMETER 5 [Pro]
22 08 pp 00 00 01 00 - 7F EFX PARAMETER 6 [Pro]
22 09 pp 00 00 01 00 - 7F EFX PARAMETER 7 [Pro]
22 0A pp 00 00 01 00 - 7F EFX PARAMETER 8 [Pro]
22 0B pp 00 00 01 00 - 7F EFX PARAMETER 9 [Pro]
22 0C pp 00 00 01 00 - 7F EFX PARAMETER 10 [Pro]
22 0D pp 00 00 01 00 - 7F EFX PARAMETER 11 [Pro]
22 0E pp 00 00 01 00 - 7F EFX PARAMETER 12 [Pro]
22 0F pp 00 00 01 00 - 7F EFX PARAMETER 13 [Pro]
22 10 pp 00 00 01 00 - 7F EFX PARAMETER 14 [Pro]
22 11 pp 00 00 01 00 - 7F EFX PARAMETER 15 [Pro]
22 12 pp 00 00 01 00 - 7F EFX PARAMETER 16 [Pro]
22 13 pp 00 00 01 00 - 7F EFX PARAMETER 17 [Pro]
22 14 pp 00 00 01 00 - 7F EFX PARAMETER 18 [Pro]
22 15 pp 00 00 01 00 - 7F EFX PARAMETER 19 [Pro]
22 16 pp 00 00 01 00 - 7F EFX PARAMETER 20 [Pro]
● User Patch
All Patch Common and Patch Part parameters (limited to Part 1 and Part 2) can be adjusted as desired, and saved as a Patch.
Patches saved in this way are referred to as User Patches. 16 different User Patches can be saved.
● User Patch Common
pp : Patch number (00 - 0F : 1-16)
