Chapter 8. Appendix
201
Address(H) Size(H) Data(H) Parameter
23 pp 00 00 00 04 0018 - 07E8 MASTER TUNE [Pro] -100.0 - +100.0 [cent]
23 pp 01#
23 pp 02#
23 pp 03#
23 pp 04 00 00 01 00 - 7F MASTER VOLUME [Pro] 0 - 127
23 pp 05 00 00 01 28 - 58 MASTER KEY-SHIFT [Pro] -24 - +24 [semitones]
23 pp 06 00 00 01 01 - 7F MASTER PAN [Pro] -63 - +63
23 pp 08 00 00 10 20 - 7F PATCH NAME [Pro] 16 ASCII Characters
23 pp : #
23 pp 17#
23 pp 18 00 00 01 00 - 07 REVERB MACRO [Pro] Room 1 - PDelay
23 pp 19 00 00 01 00 - 07 REVERB CHARACTER [Pro] 0 - 7
23 pp 1A 00 00 01 00 - 07 REVERB PRE-LPF [Pro] 0 - 7
23 pp 1B 00 00 01 00 - 7F REVERB LEVEL [Pro] 0 - 127
23 pp 1C 00 00 01 00 - 7F REVERB TIME [Pro] 0 - 127
23 pp 1D 00 00 01 00 - 7F REVERB DELAY FEEDBACK [Pro] 0 - 127
23 pp 1F 00 00 01 00 - 7F REVERB PREDELAY TIME [Pro] 0 - 127[ms]
* In MODE-2 (Double module mode), REVERB PREDELAY TIME cannot be used.
23 pp 20 00 00 01 00 - 07 CHORUS MACRO [Pro] Chorus 1 - SDelay(FB)
23 pp 21 00 00 01 00 - 07 CHORUS PRE-LPF [Pro] 0-7
23 pp 22 00 00 01 00 - 7F CHORUS LEVEL [Pro] 0-127
23 pp 23 00 00 01 00 - 7F CHORUS FEEDBACK [Pro] 0-127
23 pp 24 00 00 01 00 - 7F CHORUS DELAY [Pro] 0-127
23 pp 25 00 00 01 00 - 7F CHORUS RATE [Pro] 0-127
23 pp 26 00 00 01 00 - 7F CHORUS DEPTH [Pro] 0-127
23 pp 27 00 00 01 00 - 7F CHORUS SEND LEVEL TO REVERB [Pro] 0-127
23 pp 28 00 00 01 00 - 7F CHORUS SEND LEVEL TO DELAY [Pro] 0-127
* In MODE-2 (Double module mode), CHORUS SEND LEVEL TO DELAY cannot be used.
23 pp 29 00 00 01 00 - 09 DELAY MACRO [Pro] Delay 1 - Pan Repeat
23 pp 2A 00 00 01 00 - 07 DELAY PRE-LPF [Pro] 0 - 7
23 pp 2B 00 00 01 01 - 73 DELAY TIME CENTER [Pro] 0.1ms - 1sec
23 pp 2C 00 00 01 01 - 78 DELAY TIME RATIO LEFT [Pro] 4 - 500%
23 pp 2D 00 00 01 01 - 78 DELAY TIME RATIO RIGHT [Pro] 4 - 500%
23 pp 2E 00 00 01 00 - 7F DELAY LEVEL CENTER [Pro] 0 - 127
23 pp 2F 00 00 01 00 - 7F DELAY LEVEL LEFT [Pro] 0 - 127
23 pp 30 00 00 01 00 - 7F DELAY LEVEL RIGHT [Pro] 0 - 127
23 pp 31 00 00 01 00 - 7F DELAY LEVEL [Pro] 0 - 127
23 pp 32 00 00 01 00 - 7F DELAY FEEDBACK [Pro] -64 - +63
23 pp 33 00 00 01 00 - 7F DELAY SENDLEVEL TO REVERB [Pro] 0 - 127
* In MODE-2 (Double module mode), DELAY cannot be used.
23 pp 34 00 00 01 00 - 01 EQ LOW FREQ [Pro] 200Hz, 400Hz
23 pp 35 00 00 01 34 - 4C EQ LOW GAIN [Pro] -12 - +12dB
23 pp 36 00 00 01 00 - 01 EQ HIGH FREQ [Pro] 3kHz, 6kHz
23 pp 37 00 00 01 34 - 4C EQ HIGH GAIN [Pro] -12 - +12dB
* In MODE-2 (Double module mode), EQ cannot be used.
