Chapter 8. Appendix
203
2a pp 30 00 00 01 00 - 7F TONE MODIFY1 [Pro] -64 - +63
Vibrato Rate
2a pp 31 00 00 01 00 - 7F TONE MODIFY2 [Pro] -64 - +63
Vibrato Depth
2a pp 32 00 00 01 00 - 7F TONE MODIFY3 [Pro] -64 - +63
TVF Cutoff Freq
2a pp 33 00 00 01 00 - 7F TONE MODIFY4 [Pro] -64 - +63
TVF Resonance
2a pp 34 00 00 01 00 - 7F TONE MODIFY5 [Pro] -64 - +63
TVF&TVA Env.attack
2a pp 35 00 00 01 00 - 7F TONE MODIFY6 [Pro] -64 - +63
TVF&TVA Env.decay
2a pp 36 00 00 01 00 - 7F TONE MODIFY7 [Pro] -64 - +63
TVF&TVA Env.release
2a pp 37 00 00 01 00 - 7F TONE MODIFY8 [Pro] -64 - +63
Vibrato Delay
2a pp 40 00 00 0C 00 - 7F SCALE TUNING C [Pro] -64 - +63 [cent]
2a pp : #
2a pp 4B# 00 - 7F SCALE TUNING B [Pro] -64 - +63 [cent]
2a pp 50 00 00 01 28 - 58 MOD PITCH CONTROL [Pro] -24 - +24 [semitones]
2a pp 51 00 00 01 00 - 7F MOD TVF CUTOFF CONTROL [Pro] -9600 - +9600 [cent]
2a pp 52 00 00 01 00 - 7F MOD AMPLITUDE CONTROL [Pro] -100.0 - +100.0 [%]
2a pp 53 00 00 01 00 - 7F MOD LFO1 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2a pp 54 00 00 01 00 - 7F MOD LFO1 PITCH DEPTH [Pro] 0 - 600 [cent]
2a pp 55 00 00 01 00 - 7F MOD LFO1 TVF DEPTH [Pro] 0 - 2400 [cent]
2a pp 56 00 00 01 00 - 7F MOD LFO1 TVA DEPTH [Pro] 0 - 100.0 [%]
2a pp 57 00 00 01 00 - 7F MOD LFO2 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2a pp 58 00 00 01 00 - 7F MOD LFO2 PITCH DEPTH [Pro] 0 - 600 [cent]
2a pp 59 00 00 01 00 - 7F MOD LFO2 TVF DEPTH [Pro] 0 - 2400 [cent]
2a pp 5A 00 00 01 00 - 7F MOD LFO2 TVA DEPTH [Pro] 0 - 100.0 [%]
2a pp 60 00 00 01 40 - 58 BEND PITCH CONTROL [Pro] 0 - 24 [semitones]
2a pp 61 00 00 01 00 - 7F BEND TVF CUTOFF CONTROL [Pro] -9600 - +9600 [cent]
2a pp 62 00 00 01 00 - 7F BEND AMPLITUDE CONTROL [Pro] -100.0 - +100.0 [%]
2a pp 63 00 00 01 00 - 7F BEND LFO1 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2a pp 64 00 00 01 00 - 7F BEND LFO1 PITCH DEPTH [Pro] 0 - 600 [cent]
2a pp 65 00 00 01 00 - 7F BEND LFO1 TVF DEPTH [Pro] 0 - 2400 [cent]
2a pp 66 00 00 01 00 - 7F BEND LFO1 TVA DEPTH [Pro] 0 - 100.0 [%]
2a pp 67 00 00 01 00 - 7F BEND LFO2 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2a pp 68 00 00 01 00 - 7F BEND LFO2 PITCH DEPTH [Pro] 0 - 600 [cent]
2a pp 69 00 00 01 00 - 7F BEND LFO2 TVF DEPTH [Pro] 0 - 2400 [cent]
2a pp 6A 00 00 01 00 - 7F BEND LFO2 TVA DEPTH [Pro] 0 - 100.0 [%]
2a pp 70 00 00 01 28 - 58 CAf PITCH CONTROL [Pro] -24 - +24 [semitones]
2a pp 71 00 00 01 00 - 7F CAf TVF CUTOFF CONTROL [Pro] -9600 - +9600 [cent]
2a pp 72 00 00 01 00 - 7F CAf AMPLITUDE CONTROL [Pro] -100.0 - +100.0 [%]
2a pp 73 00 00 01 00 - 7F CAf LFO1 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2a pp 74 00 00 01 00 - 7F CAf LFO1 PITCH DEPTH [Pro] 0 - 600 [cent]
2a pp 75 00 00 01 00 - 7F CAf LFO1 TVF DEPTH [Pro] 0 - 2400 [cent]
2a pp 76 00 00 01 00 - 7F CAf LFO1 TVA DEPTH [Pro] 0 - 100.0 [%]
2a pp 77 00 00 01 00 - 7F CAf LFO2 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2a pp 78 00 00 01 00 - 7F CAf LFO2 PITCH DEPTH [Pro] 0 - 600 [cent]
2a pp 79 00 00 01 00 - 7F CAf LFO2 TVF DEPTH [Pro] 0 - 2400 [cent]
2a pp 7A 00 00 01 00 - 7F CAf LFO2 TVA DEPTH [Pro] 0 - 100.0 [%]
2b pp 00 00 00 01 28 - 58 PAf PITCH CONTROL [Pro] -24 - +24 [semitones]
2b pp 01 00 00 01 00 - 7F PAf TVF CUTOFF CONTROL [Pro] -9600 - +9600 [cent]
2b pp 02 00 00 01 00 - 7F PAf AMPLITUDE CONTROL [Pro] -100.0 - +100.0 [%]
2b pp 03 00 00 01 00 - 7F PAf LFO1 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2b pp 04 00 00 01 00 - 7F PAf LFO1 PITCH DEPTH [Pro] 0 - 600 [cent]
2b pp 05 00 00 01 00 - 7F PAf LFO1 TVF DEPTH [Pro] 0 - 2400 [cent]
2b pp 06 00 00 01 00 - 7F PAf LFO1 TVA DEPTH [Pro] 0 - 100.0 [%]
2b pp 07 00 00 01 00 - 7F PAf LFO2 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2b pp 08 00 00 01 00 - 7F PAf LFO2 PITCH DEPTH [Pro] 0 - 600 [cent]
2b pp 09 00 00 01 00 - 7F PAf LFO2 TVF DEPTH [Pro] 0 - 2400 [cent]
2b pp 0A 00 00 01 00 - 7F PAf LFO2 TVA DEPTH [Pro] 0 - 100.0 [%]
2b pp 10 00 00 01 28 - 58 CC1 PITCH CONTROL [Pro] -24 - +24 [semitones]
2b pp 11 00 00 01 00 - 7F CC1 TVF CUTOFF CONTROL [Pro] -9600 - +9600 [cent]
2b pp 12 00 00 01 00 - 7F CC1 AMPLITUDE CONTROL [Pro] -100.0 - +100.0 [%]
2b pp 13 00 00 01 00 - 7F CC1 LFO1 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2b pp 14 00 00 01 00 - 7F CC1 LFO1 PITCH DEPTH [Pro] 0 - 600 [cent]
2b pp 15 00 00 01 00 - 7F CC1 LFO1 TVF DEPTH [Pro] 0 - 2400 [cent]
2b pp 16 00 00 01 00 - 7F CC1 LFO1 TVA DEPTH [Pro] 0 - 100.0 [%]
2b pp 17 00 00 01 00 - 7F CC1 LFO2 RATE CONTROL [Pro] -10.0 - +10.0 [Hz]
2b pp 18 00 00 01 00 - 7F CC1 LFO2 PITCH DEPTH [Pro] 0 - 600 [cent]
2b pp 19 00 00 01 00 - 7F CC1 LFO2 TVF DEPTH [Pro] 0 - 2400 [cent]
2b pp 1A 00 00 01 00 - 7F CC1 LFO2 TVA DEPTH [Pro] 0 - 100.0 [%]
