Hi Gain (High gain ) -12 - +12 [18]
Adjust the high frequency gain.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
42: EH → Flanger (Enhancer → Flanger)
[02H, 07H]
This effect connects an enhancer and a flanger in
series.
+EH Sens (Enhancer Sensitivity ) 0 - 127 [1]
Adjust the sensitivity of the enhancer.
EH Mix (Enhancer Mix level ) 0 - 127 [2]
Adjust the ratio with which the overtones generated
by the enhancer are combined with the direct
sound.
FL Dly (Flanger pre delay ) 0 - 100m [6]
Adjust the time delay from when the direct sound
begins until the flanger sound is heard.
FL Rate (Flanger rate ) 0.05 - 10.0 [7]
Adjust the modulation speed of the flanger effect.
FL Depth (Flanger depth ) 0 - 127 [8]
Adjust the modulation depth of the flanger effect.
FL Fb (Flanger Feedback level ) -98% - +98% [9]
Adjust the proportion (%) of the flanger sound that
is fed back into the effect. Negative (-) settings will
invert the phase.
#FL Bal (Flanger balance) D> 0E - D 0<E [10]
Adjust the volume balance between the sound
which passes through the flanger and the sound
which does not. With a setting of D>0E, only the
enhancer sound will be output, and with a setting of
D 0<E, the enhancer sound which passes through
the flanger will be output. “D” and “E” respectively
indicate D (dry sound) and E (effect sound) values
of 100.
Low Gain -12 - +12 [17]
Adjust the low frequency gain.
Hi Gain (High gain ) -12 - +12 [18]
Adjust the high frequency gain.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
43: EH → Delay (Enhancer → Delay) [02H, 08H]
This effect connects an enhancer and a delay in
series.
+EH Sens (Enhancer Sensitivity ) 0 - 127 [1]
Adjust the sensitivity of the enhancer.
EH Mix (Enhancer Mix level ) 0 - 127 [2]
Adjust the ratio with which the overtones generated
by the enhancer are combined with the direct
sound.
Dly Time (Delay time ) 0 - 500m [6]
Adjust the time delay from when the direct sound
begins until the delay sound is heard.
Dly Fb (Delay feedback level ) -98% - +98% [7]
Adjust the proportion (%) of the delay sound that is
fed back into the delay input. Negative (-) settings
will invert the phase.
Dly HF (Delay HF damp ) 315 - 8k/Bypass [8]
Adjust the frequency above which delayed sound
fed back to the delay input will be cut. If you do not
wish to cut the high frequencies of the delay feed-
back, set this parameter to Bypass.
#Dly Bal (Delay balance ) D> 0E - D 0<E [10]
Adjust the volume balance between the sound
which passes through the delay and the sound
which does not. With a setting of D>0E, only the
enhancer sound will be output, and with a setting of
D 0<E, the enhancer sound which passes through
the delay will be output.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Low Gain -12 - +12 [17]
Adjust the low frequency gain.
Hi Gain (High gain ) -12 - +12 [18]
Adjust the high frequency gain.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
44: Cho → Delay (Chorus → Delay) [02H, 09H]
This effect connects a chorus and a delay unit in
series.
Cho Dly (Chorus pre delay ) 0 - 100m [1]
Adjust the time delay from when the direct sound
begins until the chorus sound is heard.
Enhancer
Enhancer
Flanger
L
R
EQ
EQ
Balance
Enhancer
Enhancer
Delay
L
R
EQ
EQ
Balance
L
R
Delay
EQ
EQ
Chorus
Chapter 4. Insertion Effects
75
