Chapter 8. Appendix
199
40 2x 40 00 00 01 28 - 58 CC1 PITCH CONTROL -24 - +24 [semitones] 40 0 [semitones]
40 2x 41 00 00 01 00 - 7F CC1 TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 42 00 00 01 00 - 7F CC1 AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 43 00 00 01 00 - 7F CC1 LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 44 00 00 01 00 - 7F CC1 LFO1 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 45 00 00 01 00 - 7F CC1 LFO1 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 46 00 00 01 00 - 7F CC1 LFO1 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 47 00 00 01 00 - 7F CC1 LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 48 00 00 01 00 - 7F CC1 LFO2 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 49 00 00 01 00 - 7F CC1 LFO2 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 4A 00 00 01 00 - 7F CC1 LFO2 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 50 00 00 01 28 - 58 CC2 PITCH CONTROL -24 - +24 [semitones] 40 0 [semitones]
40 2x 51 00 00 01 00 - 7F CC2 TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 52 00 00 01 00 - 7F CC2 AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 53 00 00 01 00 - 7F CC2 LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 54 00 00 01 00 - 7F CC2 LFO1 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 55 00 00 01 00 - 7F CC2 LFO1 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 56 00 00 01 00 - 7F CC2 LFO1 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 57 00 00 01 00 - 7F CC2 LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 58 00 00 01 00 - 7F CC2 LFO2 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 59 00 00 01 00 - 7F CC2 LFO2 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 5A 00 00 01 00 - 7F CC2 LFO2 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
* You may not always be able to obtain the desired effect by modifying the LFO 1 and LFO 2 parameters.
40 4x 00 00 00 01 00 - 03 TONE MAP NUMBER [Pro] MAP 0 - 3 00
(= CC#32 : Bank number LSB) 00 : SELECTED
01 : SC-55 MAP
02 : SC-88 MAP
03 : Native MAP
*When "GS Reset" is received, this will be 00: SELECTED.
40 4x 01 00 00 01 01 - 03 TONE MAP-0 NUMBER [Pro] 01 : SC-55 MAP (03)
02 : SC-88 MAP
03 : Native MAP
* When TONE MAP NUMBER is 00, this specifies the MAP. This setting will not be reset when the power is turned on or when "GS Reset", "General MIDI System On" or
"System Mode Set" is received.
40 4x 20 00 00 01 00 - 01 EQ ON/OFF [88] OFF / ON 01 ON
* This turns the EQ (equalizer) on/off. In MODE-2 (Double module mode) it cannot be used.
40 4x 21 00 00 01 00 - 03 OUTPUT ASSIGN [Pro] 00:OUTPUT-1 00 OUTPUT-1
01:OUTPUT-2
02:OUTPUT-2L
03:OUTPUT-2R
40 4x 22 00 00 01 00 - 01 PART EFX ASSIGN [Pro] 00:BYPASS 00 BYPASS
01:EFX
● Drum setup parameters
m: Map number (0 = MAP1, 1 = MAP2)
rr: drum part note number (00H - 7FH: 0 - 127)
Address(H) Size(H) Data(H) Parameter Description
41 m0 00 00 00 0C 20 - 7F DRUM MAP NAME ASCII Character
| #
41 m0 0B#
41 m1 rr 00 00 01 00 - 7F PLAY NOTE NUMBER Pitch coarse
41 m2 rr 00 00 01 00 - 7F LEVEL TVA level
(=NRPN# 26)
41 m3 rr 00 00 01 00 - 7F ASSIGN GROUP NUMBER Non, 1 - 127
41 m4 rr 00 00 01 00 - 7F PANPOT -64(RANDOM),
-63(LEFT) - +63(RIGHT)
(=NRPN# 28, except RANDOM)
41 m5 rr 00 00 01 00 - 7F REVERB SEND LEVEL 0.0 - 1.0
Multiplicand of the part reverb level
(=NRPN# 29)
41 m6 rr 00 00 01 00 - 7F CHORUS SEND LEVEL 0.0 - 1.0
Multiplicand of the part chorus level
(=NRPN# 30)
41 m7 rr 00 00 01 00 - 01 Rx. NOTE OFF OFF / ON
41 m8 rr 00 00 01 00 - 01 Rx. NOTE ON OFF / ON
41 m9 rr 00 00 01 00 - 7F DELAY SEND LEVEL [88] 0.0 - 1.0
Multiplicand of the part delay level
(=NRPN# 31)
* When the Drum Set is changed, DRUM SETUP PARAMETER values will all be initialized.
* It is not possible to simultaneously use both Chorus Send Level and Delay Send Level for a single Drum Instrument.
