Chapter 8. Appendix
184
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Pre Delay Delay Delay Delay Delay Cutoff EQ
Value(H) Time Time 1 Time 2 Time 3 Time 4 Rate1 Rate2
HF Damp
Freq Freq LPF Manual Azimuth Accl
(ms) (ms) (ms) (ms) (ms) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (deg)
40 14 520 520 14 320 3.25 3.25 2000 1600 1250 1600 1900 0 8
41 15 525 525 15 325 3.30 3.30 " " " " 2000 " "
42 16 530 530 16 330 3.35 3.35 " " " " 2100 R12 "
43 17 535 535 17 335 3.40 3.40 " " " " 2200 " "
44 18 540 540 18 340 3.45 3.45 " " " " 2300 " "
45 19 545 545 19 345 3.50 3.50 " " " " 2400 " "
46 20 550 550 20 350 3.55 3.55 " " " " 2500 R24 "
47 21 560 555 21 355 3.60 3.60 " " " " 2600 " "
48 22 570 560 22 360 3.65 3.65 2500 2000 1600 2000 2700 " 9
49 23 580 565 23 365 3.70 3.70 " " " " 2800 " "
4A 24 590 570 24 370 3.75 3.75 " " " " 2900 R36 "
4B 25 600 575 25 375 3.80 3.80 " " " " 3000 " "
4C 26 610 580 26 380 3.85 3.85 " " " " 3100 " "
4D 27 620 585 27 385 3.90 3.90 " " " " 3200 " "
4E 28 630 590 28 390 3.95 3.95 " " " " 3300 R48 "
4F 29 640 595 29 395 4.00 4.00 " " " " 3400 " "
50 30 650 600 30 400 4.05 4.05 3150 2500 2000 2500 3500 " 10
51 31 660 610 31 405 4.10 4.10 " " " " 3600 " "
52 32 670 620 32 410 4.15 4.15 " " " " 3700 R60 "
53 33 680 630 33 415 4.20 4.20 " " " " 3800 " "
54 34 690 640 34 420 4.25 4.25 " " " " 3900 " "
55 35 700 650 35 425 4.30 4.30 " " " " 4000 " "
56 36 710 660 36 430 4.35 4.35 " " " " 4100 R72 "
57 37 720 670 37 435 4.40 4.40 " " " " 4200 " "
58 38 730 680 38 440 4.45 4.45 4000 3150 2500 3150 4300 " 11
59 39 740 690 39 445 4.50 4.50 " " " " 4400 " "
5A 40 750 700 40 450 4.55 4.55 " " " " 4500 R84 "
5B 41 760 710 50 455 4.60 4.60 " " " " 4600 " "
5C 42 770 720 60 460 4.65 4.65 " " " " 4700 " "
5D 43 780 730 70 465 4.70 4.70 " " " " 4800 " "
5E 44 790 740 80 470 4.75 4.75 " " " " 4900 R96 "
5F 45 800 750 90 475 4.80 4.80 " " " " 5000 " "
60 46 810 760 100 480 4.85 4.85 5000 4000 3150 4000 5100 " 12
61 47 820 770 110 485 4.90 4.90 " " " " 5200 " "
62 48 830 780 120 490 4.95 4.95 " " " " 5300 R108 "
63 49 840 790 130 495 5.00 5.00 " " " " 5400 " "
64 50 850 800 140 500 5.10 5.05 " " " " 5500 " "
65 52 860 810 150 505 5.20 5.10 " " " " 5600 " "
66 54 870 820 160 510 5.30 5.15 " " " " 5700 R120 "
67 56 880 830 170 515 5.40 5.20 " " " " 5800 " "
68 58 890 840 180 520 5.50 5.25 6300 5000 4000 5000 5900 " 13
69 60 900 850 190 525 5.60 5.30 " " " " 6000 " "
6A 62 910 860 200 530 5.70 5.35 " " " " 6100 R132 "
6B 64 920 870 210 535 5.80 5.40 " " " " 6200 " "
6C 66 930 880 220 540 5.90 5.45 " " " " 6300 " "
6D 68 940 890 230 545 6.00 5.50 " " " " 6400 " "
6E 70 950 900 240 550 6.10 5.55 " " " " 6500 R144 "
6F 72 960 910 250 555 6.20 5.60 " " " " 6600 " "
70 74 970 920 260 560 6.30 5.65 8000 6300 5000 6300 6700 " 14
71 76 980 930 270 565 6.40 5.70 " " " " 6800 " "
72 78 990 940 280 570 6.50 5.75 " " " " 6900 R156 "
73 80 1000 950 290 575 6.60 5.80 " " " " 7000 " "
74 82 -- 960 300 580 6.70 5.85 " " " " 7100 " "
75 84 -- 970 320 585 6.80 5.90 " " " " 7200 " "
76 86 -- 980 340 590 6.90 5.95 " " " " 7300 R168 "
77 88 -- 990 360 595 7.00 6.00 " " " " 7400 " "
78 90 -- 1000 380 600 7.50 6.05 Bypass 8000 6300 Bypass 7500 " 15
79 92 -- 1000 400 605 8.00 6.10 " " " " 7600 " "
7A 94 -- 1000 420 610 8.50 6.15 " " " " 7700 R180(=L180) "
7B 96 -- 1000 440 615 9.00 6.20 " " " " 7800 " "
7C 98 -- 1000 460 620 9.50 6.25 " " " " 7900 " "
7D 100 -- 1000 480 625 10.00 6.30 " " " " 8000 " "
7E 100 -- 1000 500 630 10.00 6.35 " " " " 8000 " "
7F 100 -- 1000 500 635 10.00 6.40 " " " " 8000 " "
