Chapter 8. Appendix
198
40 1x 30 00 00 01 00 - 7F TONE MODIFY1 [88] -64 - +63 40 0
Vibrato Rate (=NRPN# 8)
40 1x 31 00 00 01 00 - 7F TONE MODIFY2 [88] -64 - +63 40 0
Vibrato Depth (=NRPN# 9)
40 1x 32 00 00 01 00 - 7F TONE MODIFY3 [88] -64 - +63 40 0
TVF Cutoff Freq. (=NRPN# 32)
40 1x 33 00 00 01 00 - 7F TONE MODIFY4 [88] -64 - +63 40 0
TVF Resonance (=NRPN# 33)
40 1x 34 00 00 01 00 - 7F TONE MODIFY5 [88] -64 - +63 40 0
TVF&TVA Env.attack (=NRPN# 99)
40 1x 35 00 00 01 00 - 7F TONE MODIFY6 [88] -64 - +63 40 0
TVF&TVA Env.decay (=NRPN# 100)
40 1x 36 00 00 01 00 - 7F TONE MODIFY7 [88] -64 - +63 40 0
TVF&TVA Env.release (=NRPN# 102)
40 1x 37 00 00 01 00 - 7F TONE MODIFY8 [88] -64 - +63 40 0
Vibrato Delay (=NRPN# 10)
40 1x 40 00 00 0C 00 - 7F SCALE TUNING C -64 - +63 [cent] 40 0 [cent]
40 1x 41# 00 - 7F SCALE TUNING C# -64 - +63 [cent] 40 0 [cent]
40 1x 42# 00 - 7F SCALE TUNING D -64 - +63 [cent] 40 0 [cent]
40 1x 43# 00 - 7F SCALE TUNING D# -64 - +63 [cent] 40 0 [cent]
40 1x 44# 00 - 7F SCALE TUNING E -64 - +63 [cent] 40 0 [cent]
40 1x 45# 00 - 7F SCALE TUNING F -64 - +63 [cent] 40 0 [cent]
40 1x 46# 00 - 7F SCALE TUNING F# -64 - +63 [cent] 40 0 [cent]
40 1x 47# 00 - 7F SCALE TUNING G -64 - +63 [cent] 40 0 [cent]
40 1x 48# 00 - 7F SCALE TUNING G# -64 - +63 [cent] 40 0 [cent]
40 1x 49# 00 - 7F SCALE TUNING A -64 - +63 [cent] 40 0 [cent]
40 1x 4A# 00 - 7F SCALE TUNING A# -64 - +63 [cent] 40 0 [cent]
40 1x 4B# 00 - 7F SCALE TUNING B -64 - +63 [cent] 40 0 [cent]
* SCALE TUNING is a function that allows fine adjustment to the pitch of each note in the octave. The pitch of each identically-named note in all octaves will change simultane-
ously. A setting of ± 0 cent (40H) is equal temperament (page 208).
40 2x 00 00 00 01 28 - 58 MOD PITCH CONTROL -24 - +24 [semitones] 40 0 [semitones]
40 2x 01 00 00 01 00 - 7F MOD TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 02 00 00 01 00 - 7F MOD AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 03 00 00 01 00 - 7F MOD LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 04 00 00 01 00 - 7F MOD LFO1 PITCH DEPTH 0 - 600 [cent] 0A 10 [cent]
40 2x 05 00 00 01 00 - 7F MOD LFO1 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 06 00 00 01 00 - 7F MOD LFO1 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 07 00 00 01 00 - 7F MOD LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 08 00 00 01 00 - 7F MOD LFO2 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 09 00 00 01 00 - 7F MOD LFO2 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 0A 00 00 01 00 - 7F MOD LFO2 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 10 00 00 01 40 - 58 BEND PITCH CONTROL 0 - 24 [semitones] 42 2 [semitones]
40 2x 11 00 00 01 00 - 7F BEND TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 12 00 00 01 00 - 7F BEND AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 13 00 00 01 00 - 7F BEND LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 14 00 00 01 00 - 7F BEND LFO1 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 15 00 00 01 00 - 7F BEND LFO1 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 16 00 00 01 00 - 7F BEND LFO1 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 17 00 00 01 00 - 7F BEND LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 18 00 00 01 00 - 7F BEND LFO2 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 19 00 00 01 00 - 7F BEND LFO2 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 1A 00 00 01 00 - 7F BEND LFO2 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 20 00 00 01 28 - 58 CAf PITCH CONTROL -24 - +24 [semitones] 40 0 [semitones]
40 2x 21 00 00 01 00 - 7F CAf TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 22 00 00 01 00 - 7F CAf AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 23 00 00 01 00 - 7F CAf LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 24 00 00 01 00 - 7F CAf LFO1 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 25 00 00 01 00 - 7F CAf LFO1 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 26 00 00 01 00 - 7F CAf LFO1 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 27 00 00 01 00 - 7F CAf LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 28 00 00 01 00 - 7F CAf LFO2 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 29 00 00 01 00 - 7F CAf LFO2 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 2A 00 00 01 00 - 7F CAf LFO2 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 30 00 00 01 28 - 58 PAf PITCH CONTROL -24 - +24 [semitones] 40 0 [semitones]
40 2x 31 00 00 01 00 - 7F PAf TVF CUTOFF CONTROL -9600 - +9600 [cent] 40 0 [cent]
40 2x 32 00 00 01 00 - 7F PAf AMPLITUDE CONTROL -100.0 - +100.0 [%] 40 0 [%]
40 2x 33 00 00 01 00 - 7F PAf LFO1 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 34 00 00 01 00 - 7F PAf LFO1 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 35 00 00 01 00 - 7F PAf LFO1 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 36 00 00 01 00 - 7F PAf LFO1 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
40 2x 37 00 00 01 00 - 7F PAf LFO2 RATE CONTROL -10.0 - +10.0 [Hz] 40 0 [Hz]
40 2x 38 00 00 01 00 - 7F PAf LFO2 PITCH DEPTH 0 - 600 [cent] 00 0 [cent]
40 2x 39 00 00 01 00 - 7F PAf LFO2 TVF DEPTH 0 - 2400 [cent] 00 0 [cent]
40 2x 3A 00 00 01 00 - 7F PAf LFO2 TVA DEPTH 0 - 100.0 [%] 00 0 [%]
