Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
# OD2 Drive 0 - 76 - 127 00 - 7F 09
OD2 Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 0A
OD2 Amp Sw Off/On 00/01 0B
OD2 Pan L63 - 0 - R63 00 - 7F 14
OD2 Level 0 - 84 - 127 00 - 7F 15
Level 0 - 127 00 - 7F 16
60 : OD / Rotary 11 04
OD Sel Odrv/Dist 00/01 03
+ OD Drive 0 - 48 - 127 00 - 7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
OD Pan L63 - 0 - R63 00 - 7F 12
OD Level 0 - 96 - 127 00 - 7F 13
RT L Slow 0.05 - 0.35 - 10.0 *6 08
RT L Fast 0.05 - 6.40 -10.0 *6 09
RT Lo Accl 0 - 3 - 15 *14 0A
RT Lo Lev 0 - 127 00 - 7F 0B
RT H Slow 0.05 - 0.90 - 10.0 *6 0C
RT H Fast 0.05 - 7.50 - 10.0 *6 0D
RT Hi Accl 0 - 11 - 15 *14 0E
RT Hi Lev 0 - 64 - 127 00 - 7F 0F
RT Sept 0 - 96 - 127 00 - 7F 10
# RT Speed Slow/Fast 00/7F 11
RT Pan L63 - 0 - R63 00 - 7F 14
RT Level 0 - 127 00 - 7F 15
Level 0 - 127 00 - 7F 16
61 : OD / Phaser 11 05
OD Sel Odrv/Dist 00/01 03
+ OD Drive 0 - 48 - 127 00 - 7F 04
OD Amp Smal/BltIn/ 2-Stk/3-Stk 00/01/02/03 05
OD Amp Sw Off/On 00/01 06
OD Pan L63 - 0 - R63 00 - 7F 12
OD Level 0 - 96 - 127 00 - 7F 13
PH Man 100 - 620 - 8k *12 08
# PH Rate 0.05 - 0.85 - 10.0 *6 09
PH Depth 0 - 64 - 127 00 - 7F 0A
PH Reso 0 - 16 - 127 00 - 7F 0B
PH Mix 0 - 127 00 - 7F 0C
PH Pan L63 - 0 - R63 00 - 7F 14
PH Level 0 - 127 00 - 7F 15
Level 0 - 127 00 - 7F 16
62 : OD / AutoWah 11 06
OD Sel Odrv/Dist 00/01 03
+ OD Drive 0 - 48 - 127 00 - 7F 04
OD Amp Small/BltIn/2-Stk/3-Stk 00/01/002/03 05
OD Amp Sw Off/On 00/01 06
OD Pan L63 - 0 - R63 00 - 7F 12
OD Level 0 - 96 - 127 00 - 7F 13
AW Filter LPF/BPF 00/01 08
AW Sens 0 - 127 00 - 7F 09
# AW Man 0 - 68 - 127 00 - 7F 0A
AW Peak 0 - 62 - 127 00 - 7F 0B
AW Rate 0.05 - 2.05 - 10.0 *6 0C
AW Depth 0 - 72 - 127 00 - 7F 0D
AW Pol Down/Up 00/01 0E
AW Pan L63 - 0 - R63 00 - 7F 14
AW Level 0 - 127 00 - 7F 15
Level 0 - 127 00 - 7F 16
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
63 : PH / Rotary 11 07
PH Man 100 - 620 - 8k *12 03
+ PH Rate 0.05 - 0.85 - 10.0 *6 04
PH Depth 0 - 64 - 127 00 - 7F 05
PH Reso 0 - 16 - 127 00 - 7F 06
PH Mix 0 - 127 00 - 7F 07
PH Pan L63 - 0 - R63 00 - 7F 12
PH Level 0 - 127 00 - 7F 13
RT L Slow 0.05 - 0.35 - 10.0 *6 08
RT L Fast 0.05 - 6.40 - 10.0 *6 09
RT Lo Accl 0 - 3 - 15 *14 0A
RT Lo Lev 0 - 127 00 - 7F 0B
RT H Slow 0.05 - 0.90 - 10.0 *6 0C
RT H Fast 0.05 - 7.50 - 10.0 *6 0D
RT Hi Accl 0 - 11 - 15 *14 0E
RT Hi Lev 0 - 64 - 127 00 - 7F 0F
RT Sept 0 - 96 - 127 00 - 7F 10
# RT Speed Slow/Fast 00/7F 11
RT Pan L63 - 0 - R63 00 - 7F 14
RT Level 0 - 127 00 - 7F 15
Level 0 - 127 00 - 7F 16
64 : PH / AutoWah 11 08
PH Man 100 - 620 - 8k *12 03
+ PH Rate 0.05 - 0.85 - 10.0 *6 04
PH Depth 0 - 64 - 127 00 - 7F 05
PH Reso 0 - 16 - 127 00 - 7F 06
PH Mix 0 - 127 00 - 7F 07
PH Pan L63 - 0 - R63 00 - 7F 12
PH Level 0 - 127 00 - 7F 13
AW Filter LPF/BPF 00/01 08
AW Sens 0 - 127 00 - 7F 09
# AW Man 0 - 68 - 127 00 - 7F 0A
AW Peak 0 - 62 - 127 00 - 7F 0B
AW Rate 0.05 - 2.05 - 10.0 *6 0C
AW Depth 0 - 72 - 127 00 - 7F 0D
AW Pol Down/Up 00/01 0E
AW Pan L63 - 0 - R63 00 - 7F 14
AW Level 0 - 127 00 - 7F 15
Level 0 - 127 00 - 7F 16
+: Effect control 1 can be used to modify the value (p.92)
#: Effect control 2 can be used to modify the value (p.92)
MSB/LSB: Indicates the ** portion of the following exclusive
messages. (p.196) (hexadecimal notation)
For Effect Type (data section)
F0 41 dev 42 12 40 03 00 ** ** sum F7
For Effect Parameters (LSB part of address)
F0 41 dev 42 12 40 03 ** data sum F7
(dev: device ID, sum: checksum)
The correspondence between setting values and hexadeci-
mal values for items in the Value column indicated with "*" is
shown in the "Effect Data Table" (p. 183).
*1 Pre Delay Time *8 HF Damp
*2 Delay Time 1 *9 Cutoff Freq
*3 Delay Time 2 *10 EQ Freq
*4 Delay Time 3 *11 LPF
*5 Delay Time 4 *12 Manual
*6 Rate 1 *13 Azimuth
*7 Rate 2 *14 Accl
