Wah Peak 0 - 127 [3]
Adjust the way in which the wah effect will be
applied to the region of the center frequency. Lower
settings will produce a wah effect in a broad area
around the center frequency, and higher settings
will produce a wah effect in a narrower area around
the center frequency.
Wah Sw (Wah Switch) Off/On [4]
Turn Wah on/off.
<OD (Overdrive/Distortion)>
OD Sel (OD Select) Odrv/Dist [5]
Select either Overdrive or Distortion.
#OD Drive 0 - 127 [6]
Adjust the depth of distortion. The volume will
change together with the depth of distortion.
OD Amp (OD Amp Simulator Type)
Small/BltIn/2-Stk/3-Stk [7]
Select the type of guitar amp
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
OD Amp Sw (OD Amp Switch) Off/On [8]
Turn OD Amp on/off.
OD L Gain (OD Low Gain) -12 - +12 [9]
Adjust the low-range gain for the overdrive (or dis-
tortion) sound.
OD H Gain (OD High Gain) -12 - +12 [10]
Adjust the high-range gain for the overdrive (or dis-
tortion) sound.
OD Sw (OD Switch) Off/On [11]
Turn overdrive or distortion on/off.
<CF (Chorus/Flanger)>
CF Sel (CF Select) Chorus/Flangr [12]
Select either Chorus or Flanger.
CF Rate 0.05 - 6.40 [13]
Adjust the modulation speed for the chorus or
flanger.
CF Depth 0 - 127 [14]
Adjust the modulation depth for the chorus or
flanger.
CF Fb (CF Feedback) -98% - +98% [15]
Adjust the amount (%) of the flanger sound that is
returned to the input. Negative (-) values will invert
the phase.
In the case of Chorus, this will have no effect.
CF Mix 0 - 127 [16]
Adjust the volume of the chorus or flanger sound.
<Dly (Delay)>
Dly Time (Delay Time) 0m - 635m [17]
Adjust the time from the original sound until when
the delay sound is heard.
Dly Fb (Delay Feedback Level) 0 - 127 [18]
Adjust the amount of the delay sound that is
returned to the input.
Dly Mix (Delay Mix) 0 - 127 [19]
Adjust the volume of the delay sound.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
51: Clean Gt Multi1 (Clean Guitar Multi1)
[04H, 03H]
Clean Guitar Multi 1 connects Compressor (Cmp),
Equalizer (EQ), Chorus or Flanger (CF), and Delay
(Dly) effects in series.
<Cmp (Compressor)>
Cmp Atck (Compressor Attack) 0 - 127 [1]
Adjust the time over which the sound will rise after it
is input.
Cmp Sus (Compressor Sustain) 0 - 127 [2]
Adjust the time over which low-level sounds are
boosted until they reach a specified volume.
Increasing the value will shorten the time. When the
value is modified, the level will also change.
Cmp Level (Compressor Level) 0 - 127 [3]
Adjust the volume of the compressor sound.
Cmp Sw (Compressor Switch) Off/On [4]
Turn the compressor on/off.
<EQ (Equalizer)>
EQ L Gain (EQ Low Gain) -12 - +12 [5]
Adjust the low-range gain of the equalizer.
EQ M Fq (EQ Mid Frequency) 200 - 6.3k [6]
Set the center frequency for the equalizer mid-
range.
EQ M Q (EQ Mid Q) 0.5/1.0/2.0/4.0/9.0 [7]
Adjust the width of the area centered at the EQ M
Fq setting in which the gain will be affected. The
area affected will become narrower as this value is
increased.
L
R
DelayCmp
CF
EQ
