Chapter 8. Appendix
181
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
52 : Clean Gt Multi2 04 04
AW Filter LPF/BPF 00/01 03
+ AW Man 0 - 55 - 127 00 - 7F 04
AW Peak 0 - 40 - 127 00 - 7F 05
AW Rate 0.05 - 1.50 - 6.40 *7 06
AW Depth 0 - 80 - 127 00 - 7F 07
AW Sw Off/On 00/01 08
EQ L Gain -12 - +12 34 - 4C 09
EQ M Fq 200 - 1.6k - 6.3k *10 0A
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0B
EQ M Gain -12 - 0 - +12 34 - 4C 0C
EQ H Gain -12 - 0 - +12 34 - 4C 0D
CF Sel Chorus/Flangr 00/01 0E
CF Rate 0.05 - 0.45 - 6.40 *7 0F
CF Depth 0 - 20 - 127 00 - 7F 10
CF Fb -98% - +76% - +98% 0F - 71 11
CF Mix 0 - 100 - 127 00 - 7F 12
Dly Time 0m - 30m - 635m *5 13
Dly Fb 0 - 15 - 127 00 - 7F 14
# Dly Mix 0 - 80 - 127 00 - 7F 15
Level 0 - 76 - 127 00 - 7F 16
53 : Bass Multi 04 05
Cmp Atck 0 - 72 - 127 00 - 7F 03
Cmp Sus 0 - 100 - 127 00 - 7F 04
Cmp Level 0 - 75 - 127 00 - 7F 05
Cmp Sw Off/On 00/01 06
OD Sel Odrv/Dist 00/01 07
+ OD Drive 0 - 48 - 127 00 - 7F 08
OD Amp Small/BltIn/2-Stk 00/01/02 09
OD Amp Sw Off/On 00/01 0A
OD Sw Off/On 00/01 0B
EQ L Gain -12 - +2 - +12 34 - 4C 0C
EQ M Fq 200 - 1.6k - 6.3k *10 0D
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 0E
EQ M Gain -12 - +4 - +12 34 - 4C 0F
EQ H Gain -12 - 0 - +12 34 - 4C 10
CF Sel Chorus/Flangr 00/01 11
CF Rate 0.05 - 0.30 - 6.40 *7 12
CF Depth 0 - 20 - 127 00 - 7F 13
CF Fb -98% - +76% - +98% 0F - 71 14
# CF Mix 0 - 64 - 127 00 - 7F 15
Level 0 - 76 - 127 00 - 7F 16
54 : Rhodes Multi 04 06
EH Sens 0 - 64 - 127 00 - 7F 03
EH Mix 0 - 64 - 127 00 - 7F 04
PH Man 100 - 620 - 8k *12 05
PH Rate 0.05 - 0.85 - 6.40 *7 06
PH Depth 0 - 32 - 127 00 - 7F 07
PH Reso 0 - 16 - 127 00 - 7F 08
PH Mix 0 - 64 - 127 00 - 7F 09
CF Sel Chorus/Flangr 00/01 0A
CF LPF 250 - 6.3k/Bypass *11 0B
CF Dly 0 - 1.0m - 100m *1 0C
CF Rate 0.05 - 0.45 - 6.40 *7 0D
CF Depth 0 - 64 - 127 00 - 7F 0E
CF Fb -98% - +80% - +98% 0F - 71 0F
CF Mix 0 - 127 00 - 7F 10
TP Sel Trem/Pan 00/01 11
TP Mod WV Tri/Sqr/Sin/Saw1/Saw2 00/01/02/03/04 12
+ TP Mod RT 0.05 - 3.05 - 6.40 *7 13
# TP Mod Dep 0 - 64 - 127 00 - 7F 14
TP Sw Off/On 00/01 15
Level 0 - 127 00 - 7F 16
55 : Keyboard Multi 05 00
+ RM Mod Freq 0 - 50 - 127 00 - 7F 03
# RM Bal D> 0E - D>30E - D 0<E 00 - 7F 04
EQ L Gain -12 - +3 - +12 34 - 4C 05
EQ M Fq 200 - 6.3k *10 06
EQ M Q 0.5/1.0/2.0/4.0/9.0 00/01/02/03/04 07
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
EQ M Gain -12 - +5 - +12 34 - 4C 08
EQ H Gain -12 - -3 - +12 34 - 4C 09
PS Coarse -24 - +7 - +12 28 - 4C 0A
PS Fine -100 - 0 - +100 0E - 72 0B
PS Mode 1 - 5 00 - 04 0C
PS Bal D> 0E - D>60E - D 0<E 00 - 7F 0D
PH Man 100 - 620 - 8k *12 0E
PH Rate 0.05 - 0.45 - 6.40 *7 0F
PH Depth 0 - 90 - 127 00 - 7F 10
PH Reso 0 - 80 - 127 00 - 7F 11
PH Mix 0 - 75 - 127 00 - 7F 12
Dly Time 0m - 100m - 635m *5 13
Dly Fb 0 - 64 - 127 00 - 7F 14
Dly Mix 0 - 40 - 127 00 - 7F 15
Level 0 - 96 - 127 00 - 7F 16
Effects that connect two types of effect in paral-
lel (parallel 2)
56 : Cho / Delay 11 00
Cho Dly 0 - 1.0m - 100m *1 03
Cho Rate 0.05 - 0.45 - 10.0 *6 04
Cho Depth 0 - 120 - 127 00 - 7F 05
+ Cho Bal D> 0E - D=E - D 0<E 00 - 7F 07
Cho Pan L63 - 0 - R63 00 - 7F 12
Cho Level 0 - 127 00 - 7F 13
Dly Time 0 - 250m - 500m *4 08
Dly Fb -98% - +32% - +98% 0F - 71 09
Dly HF 315 - 8k/Bypass *8 0A
# Dly Bal D> 0E - D>61E - D 0<E 00 - 7F 0C
Dly Pan L63 - 0 - R63 00 - 7F 14
Dly Level 0 - 127 00 - 7F 15
Level 0 - 96 - 127 00 - 7F 16
57 : FL / Delay 11 01
FL Dly 0 - 1.6m - 100m *1 03
FL Rate 0.05 - 0.60 - 10.0 *6 04
FL Depth 0 - 24 - 127 00 - 7F 05
FL Fb -98% - +80% - +98% 0F - 71 06
+ FL Bal D> 0E - D=E - D 0<E 00 - 7F 07
FL Pan L63 - 0 - R63 00 - 7F 12
FL Level 0 - 127 00 - 7F 13
Dly Time 0 - 250m - 500m *4 08
Dly Fb -98% - +32% - +98% 0F - 71 09
Dly HF 315 - 8k/Bypass *8 0A
# Dly Bal D> 0E - D>74E - D 0<E 00 - 7F 0C
Dly Pan L63 - 0 - R63 00 - 7F 14
Dly Level 0 - 127 00 - 7F 15
Level 0 - 96 - 127 00 - 7F 16
58 : Cho / Flanger 11 02
Cho Dly 0 - 1.6m - 100m *1 03
Cho Rate 0.05 - 0.45 - 10.0 *6 04
Cho Depth 0 - 120 - 127 00 - 7F 05
+ Cho Bal D> 0E - D=E - D 0<E 00 - 7F 07
Cho Pan L63 - 0 - R63 00 - 7F 12
Cho Level 0 - 127 00 - 7F 13
FL Dly 0 - 1.6m - 100m *1 08
FL Rate 0.05 - 0.60 - 10.0 *6 09
FL Depth 0 - 24 - 127 00 - 7F 0A
FL Fb -98% - +80% - +98% 0F - 71 0B
# FL Bal D> 0E - D=E - D 0<E 00 - 7F 0C
FL Pan L63 - 0 - R63 00 - 7F 14
FL Level 0 - 127 00 - 7F 15
Level 0 - 88 -127 00 - 7F 16
59 : OD1 / OD2 11 03
OD1 Sel Odrv/Dist 00/01 03
+ OD1 Drive 0 - 48 - 127 00 - 7F 04
OD1 Amp Small/BltIn/2-Stk/3-Stk 00/01/02/03 05
OD1 Amp Sw Off/On 00/01 06
OD1 Pan L63 - 0 - R63 00 - 7F 12
OD1 Level 0 - 96 - 127 00 - 7F 13
OD2 Sel Odrv/Dist 00/01 08
