Roland SC-88 Pro Musical Instrument User Manual



Chapter 8. Appendix
177
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
12 : Tremolo 01 25
Mod Wave Tri/Sqr/Sin/Saw1/Saw2 00/01/02/03/04 03
+ Mod Rate 0.05 - 3.05 - 10.0 *6 04
# Mod Depth 0 - 96 - 127 00 - 7F 05
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
13 : Auto Pan 01 26
Mod Wave Tri/Sqr/Sin/Saw1/Saw2 00/01/02/03/04 03
+ Mod Rate 0.05 - 3.05 - 10.0 *6 04
# Mod Depth 0 - 96 - 127 00 - 7F 05
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
Effects that affect the level (compressor type)
14 : Compressor 01 30
Attack 0 - 72 - 127 00 - 7F 03
Sustain 0 - 100 - 127 00 - 7F 04
Post Gain 0/+6/+12/+18 00/01/02/03 05
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
+ Pan L63 - 0 - R63 00 - 7F 15
# Level 0 - 104 - 127 00 - 7F 16
15 : Limiter 01 31
Threshold 0 - 85 - 127 00 - 7F 03
Ratio 1/1.5,1/2,1/4,1/100 00/01/02/03 04
Release 0 - 16 - 127 00 - 7F 05
Post Gain 0/+6/+12/+18 00/01/02/03 06
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
+ Pan L63 - 0 - R63 00 - 7F 15
# Level 0 - 127 00 - 7F 16
Effects that broaden the sound (chorus type)
16 : Hexa Chorus 01 40
Pre Dly 0 - 2.4m - 100m *1 03
+ Rate 0.05 - 0.45 - 10.0 *6 04
Depth 0 - 127 00 - 7F 05
Pre Dly Dev 0 - 5 - 20 00 - 14 06
Depth Dev -20 - +2 - +20 2C - 54 07
Pan Dev 0 - 16 - 20 00 - 14 08
# Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 112 - 127 00 - 7F 16
17 : Tremolo Chorus 01 41
Pre Dly 0 - 1.6m - 100m *1 03
Cho Rate 0.05 - 0.45 - 10.0 *6 04
Cho Depth 0 - 40 - 127 00 - 7F 05
Trem Phase 0 - 80 - 180 00 - 5A 06
+ Trem Rate 0.05 - 3.05 - 10.0 *6 07
Trem Sep 0 - 96 - 127 00 - 7F 08
# Balance D> 0E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
18 : Stereo Chorus 01 42
Pre Filter Off/LPF/HPF 00/01/02 03
Cutoff 250 - 8k *9 04
Pre Dly 0 - 1.0m - 100m *1 05
+ Rate 0.05 - 0.45 - 10.0 *6 06
Depth 0 - 111 - 127 00 - 7F 07
Phase 0 - 180 00 - 5A 09
# Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 104 - 127 00 - 7F 16
Parameter Value (Dec.)
Value (Hex.) min - max
MSB/LSB(H)
19 : Space D 01 43
Pre Dly 0 - 3.2m - 100m *1 03
+ Rate 0.05 - 0.45 - 10.0 *6 04
Depth 0 - 127 00 - 7F 05
Phase 0 - 180 00 - 5A 06
# Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 96 - 127 00 - 7F 16
20 : 3D Chorus 01 44
Pre Dly 0 - 1.0m - 100m *1 03
+ Cho Rate 0.05 - 0.45 - 10.0 *6 04
Cho Depth 0 - 72 - 127 00 - 7F 05
Out Speaker/Phones 00/01 11
# Balance D> 0E - D=E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 80 - 127 00 - 7F 16
Effects that reverberate the sound (delay/reverb
type)
21 : Stereo Delay 01 50
Dly Tm L 0 - 150m - 500m *4 03
Dly Tm R 0 - 300m - 500m *4 04
+ Feedback -98% - +48% - +98% 0F - 71 05
Fb Mode Norm/Cross 00/01 06
Phase L Norm/Invert 00/01 07
Phase R Norm/Invert 00/01 08
HF Damp 315 - 8k/Bypass *8 0A
# Balance D> 0E - D>74E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
22 : Mod Delay 01 51
Dly Tm L 0 - 40m - 500m *4 03
Dly Tm R 0 - 220m - 500m *4 04
Feedback -98% - +48% - +98% 0F - 71 05
Fb Mode Norm/Cross 00/01 06
+ Mod Rate 0.05 - 0.65 - 10.0 *6 07
Mod Depth 0 - 21 - 127 00 - 7F 08
Mod Phase 0 - 180 00 - 5A 09
HF Damp 315 - 8k/Bypass *8 0A
# Balance D> 0E - D>61E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
23 : 3 Tap Delay 01 52
Dly Tm C 200m - 300m - 990m/1sec*2 03
Dly Tm L 200m - 200m - 990m/1sec*2 04
Dly Tm R 200m - 235m - 990m/1sec*2 05
+ Feedback -98% - +32% - +98% 0F - 71 06
Dly Lev C 0 - 127 00 - 7F 07
Dly Lev L 0 - 127 00 - 7F 08
Dly Lev R 0 - 127 00 - 7F 09
HF Damp 315 - 8k/Bypass *8 0A
# Balance D> 0E - D>74E - D 0<E 00 - 7F 12
Low Gain -12 - 0 - +12 34 - 4C 13
Hi Gain -12 - 0 - +12 34 - 4C 14
Level 0 - 127 00 - 7F 16
24 : 4 Tap Delay 01 53
Dly Tm 1 200m - 500m - 990m/1sec*2 03
Dly Tm 2 200m - 300m - 990m/1sec*2 04
Dly Tm 3 200m - 400m - 990m/1sec*2 05
Dly Tm 4 200m - 200m - 990m/1sec*2 06
Dly Lev 1 0 - 127 00 - 7F 07
Dly Lev 2 0 - 127 00 - 7F 08
Dly Lev 3 0 - 127 00 - 7F 09
Dly Lev 4 0 - 127 00 - 7F 0A
+ Feedback -98% - +32% - +98% 0F - 71 0B
HF Damp 315 - 8k/Bypass *8 0C
