56: Cho / Delay (Chorus / Delay) [11H, 00H]
This effect connects a chorus and a delay in parallel.
Cho Dly (Chorus pre delay ) 0 - 100m [1]
Adjust the time delay from when the direct sound
begins until the chorus sound is heard.
Cho Rate (Chorus rate ) 0.05 - 10.0 [2]
Adjust the modulation speed of the chorus effect.
Cho Depth (Chorus depth ) 0 - 127 [3]
Adjust the modulation depth of the chorus effect.
+Cho Bal (Chorus balance ) D> 0E - D 0<E [5]
Adjust the volume balance between the direct and
the chorus sound.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Cho Pan (Chorus Output Pan) L63 - 0 - R63 [16]
Adjust the stereo position of the chorus sound. L63
is far left, 0 is center, and R63 is far right.
Cho Level (Chorus Level) 0 - 127 [17]
Adjust the volume of the chorus sound.
Dly Time (Delay time ) 0 - 500m [6]
Adjust the time delay from when the direct sound
begins until the delay sound is heard.
Dly Fb (Delay feedback level ) -98% - +98% [7]
Adjust the proportion (%) of the delay sound that is
fed back into the delay input. Negative (-) settings
will invert the phase.
Dly HF (Delay HF damp ) 315 - 8k/Bypass [8]
Adjust the frequency above which delayed sound
fed back to the delay input will be cut. If you do not
wish to cut the high frequencies of the feedback, set
this parameter to Bypass.
#Dly Bal (Delay balance ) D> 0E - D 0<E [10]
Adjust the volume balance between the direct and
the delay sound.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
Dly Pan (Delay Output Pan) L63 - 0 - R63 [18]
Adjust the stereo position of the delay sound. L63 is
far left, 0 is center, and R63 is far right.
Dly Level (Delay level ) 0 - 127 [19]
Adjust the volume of the delay sound.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
57: FL / Delay (Flanger / Delay) [11H, 01H]
This effect connects a flanger and a delay in parallel.
FL Dly (Flanger pre delay ) 0 - 100m [1]
Adjust the time delay from when the direct sound
begins until the flanger sound is heard.
FL Rate (Flanger rate ) 0.05 - 10.0 [2]
Adjust the modulation speed of the flanger effect.
FL Depth (Flanger depth ) 0 - 127 [3]
Adjust the modulation depth of the flanger effect.
FL Fb (Flanger feedback level ) -98% - +98% [4]
Adjust the proportion (%) of the flanger sound that
is fed back into the effect. Negative (-) settings will
invert the phase.
+FL Bal (Flanger balance ) D> 0E - D 0<E [5]
Adjust the volume balance between the direct and
the flanger sound.
“D” or “E” on the display respectively means
D(direct sound) or E(effect sound) values of 100.
FL Pan (Flanger Output Pan) L63 - 0 - R63 [16]
Adjust the stereo position of the flanger sound. L63
is far left, 0 is center, and R63 is far right.
FL Level (Flanger level ) 0 - 127 [17]
Adjust the volume of the flanger sound.
Dly Time (Delay time ) 0 - 500m [6]
Adjust the time delay from when the direct sound
begins until the delay sound is heard.
Dly Fb (Delay feedback level ) -98% - +98% [7]
Adjust the proportion (%) of the delay sound that is
fed back into the delay input. Negative (-) settings
will invert the phase.
Dly HF (Delay HF damp ) 315 - 8k/Bypass [8]
Adjust the frequency above which delayed sound
fed back to the delay input will be cut. If you do not
want to cut the high frequencies of the delay feed-
back, set this parameter to Bypass.
L
R
Rotary
Overdrive/
Distortion
Pan
Pan
028 Clean Gt.
Part 01 L63
017 Organ 1
Part 02 R63
60 OD/Rotary
L
R
Chorus
Delay
Balance
Pan
Pan
L
R
Flanger
Delay
Balance
Pan
Pan
Chapter 4. Insertion Effects
85
