Roland SC-88 Pro Musical Instrument User Manual



Band 1 (Band 1 gain) -12 - +12 [1]
Adjust the 250 Hz level.
Band 2 (Band 2 gain) -12 - +12 [2]
Adjust the 500 Hz level.
Band 3 (Band 3 gain) -12 - +12 [3]
Adjust the 1000 Hz (1 kHz) level.
Band 4 (Band 4 gain) -12 - +12 [4]
Adjust the 1250 Hz level.
Band 5 (Band 5 gain) -12 - +12 [5]
Adjust the 2000 Hz level.
Band 6 (Band 6 gain) -12 - +12 [6]
Adjust the 3150 Hz level.
Band 7 (Band 7 gain) -12 - +12 [7]
Adjust the 4000 Hz level.
Band 8 (Band 8 gain) -12 - +12 [8]
Adjust the 8000 Hz level.
Width (Band width) 0.5/1.0/2.0/4.0/9.0 [9]
Adjust the width of the frequency bands whose gain
is being modified (common to all bands). Higher
settings will make the frequency band narrower.
+Pan (Output pan) L63 - 0 - R63 [19]
Adjust the stereo location of the output sound. L63
is far left, 0 is center, and R63 is far right.
#Level (Output level) 0 - 127 [20]
Adjust the output level.
3: Enhancer [01H, 02H]
The Enhancer controls the overtone structure of the
high frequencies, adding sparkle and tightness to the
sound.
+Sens (Sensitivity) 0 - 127 [1]
Adjust the sensitivity of the enhancer.
#Mix (Mix level) 0 - 127 [2]
Adjust the ratio with which the overtones generated
by the enhancer are combined with the direct
sound.
Low Gain -12 - +12 [17]
Adjust the gain of the low frequency range.
Hi Gain -12 - +12 [18]
Adjust the gain of the high frequency range.
Level (Output level) 0 - 127 [20]
Adjust the output level.
4: Humanizer [01H, 03H]
This adds a vowel character to the sound, making it
similar to a human voice.
Drive 0 - 127 [1]
Adjust the depth of distortion.
Drive Sw Off/On [2]
Turn Drive on/off.
+Vowel a/i/u/e/o [3]
Select the vowel.
Accel 0 - 15 [4]
Adjust the time over which the sound will move to
the specified Vowel. Smaller values will require
more time.
Low Gain -12 - +12 [17]
Adjust the low frequency gain.
Hi Gain (High gain) -12 - +12 [18]
Adjust the high frequency gain.
Pan (Output Pan) L63 - 0 - R63 [19]
Adjust the stereo position of the output sound. L63
is far left, 0 is center, and R63 is far right.
#Level (Output level) 0 - 127 [20]
Adjust the output volume.
Effects that distort the sound (distortion
type)
5: Overdrive [01H, 10H]
This effect creates a soft distortion similar to that pro-
duced by tube amplifiers.
+Drive 0 - 127 [1]
Adjust the degree of distortion.
Amp Type (Amp simulator type)
Small/BltIn/2-Stk/3-Stk [2]
Select the type of guitar amp.
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
L
R
Spectrum
Pan
L
R
Enhancer
Enhancer
Mix
EQ
EQ
L
R
Humanizer
EQ
Pan
Amp
Simulator
EQ
Pan
L
R
Over
drive
Chapter 4. Insertion Effects
58
