RT H Fast (RTRT High Frequency Fast Rate)
0.05 - 10.0 [13]
Adjust the speed of the high-range rotor for the
high-speed (Fast) setting.
RT Hi Accl (RT High Frequency Accelaration)
0 - 15 [14]
Adjust the time over which the rotation speed of the
high-range rotor will change from low-speed to
high-speed (or high-speed to low-speed) rotation.
Smaller values will require greater time to reach the
new rotational speed.
RT Hi Lev (RT High Frequency Level)
0 - 127 [15]
Adjust the volume of the high-range rotor.
RT Sept (RT Separation) 0 - 127 [16]
Adjust the spatial spread of the rotary sound.
#RT Speed Slow/Fast [17]
Simultaneously switch the rotational speed of both
the low-range and the high-range rotors.
Slow : Slow down the rotation to the speci-
fied speeds (RT L Slow parameter /
RT H Slow parameter values).
Fast : Speed up the rotation to the specified
speeds (RT L Fast parameter / RT H
Fast parameter values).
Level (Output level ) 0 - 127 [20]
Adjust the output level.
48: GTR Multi 1 (Guitar Multi1) [04H, 00H]
Guitar Multi 1 connects Compressor (Cmp), Overdrive
or Distortion (OD), Chorus or Flanger (CF), and Delay
(Dly) effects in series.
<Cmp (Compressor)>
Cmp Atck (Compressor Attack) 0 - 127 [1]
Adjust the time over which the sound will rise after
input.
Cmp Sus (Compressor Sustain) 0 - 127 [2]
Adjust the time over which low-level sounds are
boosted until they reach a specified volume.
Increasing the value will shorten the time. When the
value is modified, the level will also change.
Cmp Level (Compressor Level) 0 - 127 [3]
Adjust the volume of the compressor sound.
Cmp Sw (Compressor Switch) Off/On [4]
Turn the compressor on/off.
<OD (Overdrive/Distortion)>
OD Sel (OD Select) Odrv/Dist [5]
Select either Overdrive or Distortion.
+OD Drive 0 - 127 [6]
Adjust the depth of distortion. The volume will
change together with the depth of distortion.
OD Amp (OD Amp Simulator Type)
Small/BltIn/2-Stk/3-Stk [7]
Select the type of guitar amp.
Small : small amp
BltIn : single-unit type amp
2-Stk : large double stack amp
3-Stk : large triple stack amp
OD Amp Sw (OD Amp Switch) Off/On [8]
Turn OD Amp on/off.
OD L Gain (OD Low Gain) -12 - +12 [9]
Adjust the low-range gain.
OD H Gain (OD High Gain) -12 - +12 [10]
Adjust the high-range gain.
OD Sw (OD Switch) Off/On [11]
Turn Overdrive or Distortion on/off.
<CF (Chorus/Flanger)>
CF Sel (CF Select) Chorus/Flangr [12]
Select either Chorus or Flanger.
CF Rate 0.05 - 6.40 [13]
Adjust the speed of modulation
CF Depth 0 - 127 [14]
Adjust the depth of modulation.
CF Fb (CF Feedback) -98% - +98% [15]
Adjust the amount (%) of the flanger sound that is
returned to the input. Negative (-) values will invert
the phase.
In the case of Chorus, this will have no effect.
CF Mix 0 - 127 [16]
Adjust the volume of the chorus or flanger sound.
<Dly(Delay)>
Dly Time (Delay Time) 0m - 635m [17]
Adjust the time from the original sound until when
the delay sound is heard.
Dly Fb (Delay Feedback Level) 0 - 127 [18]
Adjust the amount of the delay sound that is
returned to the input.
#Dly Mix (Delay Mix) 0 - 127 [19]
Adjust the volume of the delay sound.
Level (Output level ) 0 - 127 [20]
Adjust the output level.
L
R
DelayCmp
CF
OD
Chapter 4. Insertion Effects
78
