Chapter 8. Appendix
183
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Pre Delay Delay Delay Delay Delay Cutoff EQ
Value(H) Time Time 1 Time 2 Time 3 Time 4 Rate1 Rate2
HF Damp
Freq Freq LPF Manual Azimuth Accl
(ms) (ms) (ms) (ms) (ms) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (deg)
00 0.0 200 200 0.0 0 0.05 0.05 315 250 200 250 100 L180(=R180) 0
01 0.1 205 205 0.1 5 0.10 0.10 " " " " 110 " "
02 0.2 210 210 0.2 10 0.15 0.15 " " " " 120 " "
03 0.3 215 215 0.3 15 0.20 0.20 " " " " 130 " "
04 0.4 220 220 0.4 20 0.25 0.25 " " " " 140 " "
05 0.5 225 225 0.5 25 0.30 0.30 " " " " 150 " "
06 0.6 230 230 0.6 30 0.35 0.35 " " " " 160 L168 "
07 0.7 235 235 0.7 35 0.40 0.40 " " " " 170 " "
08 0.8 240 240 0.8 40 0.45 0.45 400 315 250 315 180 " 1
09 0.9 245 245 0.9 45 0.50 0.50 " " " " 190 " "
0A 1.0 250 250 1.0 50 0.55 0.55 " " " " 200 L156 "
0B 1.1 255 255 1.1 55 0.60 0.60 " " " " 210 " "
0C 1.2 260 260 1.2 60 0.65 0.65 " " " " 220 " "
0D 1.3 265 265 1.3 65 0.70 0.70 " " " " 230 " "
0E 1.4 270 270 1.4 70 0.75 0.75 " " " " 240 L144 "
0F 1.5 275 275 1.5 75 0.80 0.80 " " " " 250 " "
10 1.6 280 280 1.6 80 0.85 0.85 500 400 315 400 260 " 2
11 1.7 285 285 1.7 85 0.90 0.90 " " " " 270 " "
12 1.8 290 290 1.8 90 0.95 0.95 " " " " 280 L132 "
13 1.9 295 295 1.9 95 1.00 1.00 " " " " 290 " "
14 2.0 300 300 2.0 100 1.05 1.05 " " " " 300 " "
15 2.1 305 305 2.1 105 1.10 1.10 " " " " 320 " "
16 2.2 310 310 2.2 110 1.15 1.15 " " " " 340 L120 "
17 2.3 315 315 2.3 115 1.20 1.20 " " " " 360 " "
18 2.4 320 320 2.4 120 1.25 1.25 630 500 400 500 380 " 3
19 2.5 325 325 2.5 125 1.30 1.30 " " " " 400 " "
1A 2.6 330 330 2.6 130 1.35 1.35 " " " " 420 L108 "
1B 2.7 335 335 2.7 135 1.40 1.40 " " " " 440 " "
1C 2.8 340 340 2.8 140 1.45 1.45 " " " " 460 " "
1D 2.9 345 345 2.9 145 1.50 1.50 " " " " 480 " "
1E 3.0 350 350 3.0 150 1.55 1.55 " " " " 500 L96 "
1F 3.1 355 355 3.1 155 1.60 1.60 " " " " 520 " "
20 3.2 360 360 3.2 160 1.65 1.65 800 630 500 630 540 " 4
21 3.3 365 365 3.3 165 1.70 1.70 " " " " 560 " "
22 3.4 370 370 3.4 170 1.75 1.75 " " " " 580 L84 "
23 3.5 375 375 3.5 175 1.80 1.80 " " " " 600 " "
24 3.6 380 380 3.6 180 1.85 1.85 " " " " 620 " "
25 3.7 385 385 3.7 185 1.90 1.90 " " " " 640 " "
26 3.8 390 390 3.8 190 1.95 1.95 " " " " 660 L72 "
27 3.9 395 395 3.9 195 2.00 2.00 " " " " 680 " "
28 4.0 400 400 4.0 200 2.05 2.05 1000 800 630 800 700 " 5
29 4.1 405 405 4.1 205 2.10 2.10 " " " " 720 " "
2A 4.2 410 410 4.2 210 2.15 2.15 " " " " 740 L60 "
2B 4.3 415 415 4.3 215 2.20 2.20 " " " " 760 " "
2C 4.4 420 420 4.4 220 2.25 2.25 " " " " 780 " "
2D 4.5 425 425 4.5 225 2.30 2.30 " " " " 800 " "
2E 4.6 430 430 4.6 230 2.35 2.35 " " " " 820 L48 "
2F 4.7 435 435 4.7 235 2.40 2.40 " " " " 840 " "
30 4.8 440 440 4.8 240 2.45 2.45 1250 1000 800 1000 860 " 6
31 4.9 445 445 4.9 245 2.50 2.50 " " " " 880 " "
32 5.0 450 450 5.0 250 2.55 2.55 " " " " 900 L36 "
33 5.5 455 455 5.5 255 2.60 2.60 " " " " 920 " "
34 6.0 460 460 6.0 260 2.65 2.65 " " " " 940 " "
35 6.5 465 465 6.5 265 2.70 2.70 " " " " 960 " "
36 7.0 470 470 7.0 270 2.75 2.75 " " " " 980 L24 "
37 7.5 475 475 7.5 275 2.80 2.80 " " " " 1000 " "
38 8.0 480 480 8.0 280 2.85 2.85 1600 1250 1000 1250 1100 " 7
39 8.5 485 485 8.5 285 2.90 2.90 " " " " 1200 " "
3A 9.0 490 490 9.0 290 2.95 2.95 " " " " 1300 L12 "
3B 9.5 495 495 9.5 295 3.00 3.00 " " " " 1400 " "
3C 10 500 500 10 300 3.05 3.05 " " " " 1500 " "
3D 11 505 505 11 305 3.10 3.10 " " " " 1600 " "
3E 12 510 510 12 310 3.15 3.15 " " " " 1700 0 "
3F 13 515 515 13 315 3.20 3.20 " " " " 1800 " "
■ Effect data table
