80386
2.
BASE
ARCHITECTURE
2.1
INTRODUCTION
The
B03B6
consists of a central processing unit, a
memory management unit and a bus interface.
The
central processing unit consists of the execu-
tion unit and instruction unit. The execution unit con-
tains the eight 32-bit general purpose registers
which are used for both address
calculation, data
operations and a 64-bit
barrel shifter used to speed
shift, rotate,
multiply, and divide operations. The
multiply and divide logic uses a 1-bit per cycle algo-
rithm. The multiply algorithm stops the iteration
when the most significant bits of the
multiplier are all
zero. This allows typical 32-bit multiplies to
be
exe-
cuted
in
under one microsecond. The instruction unit
decodes the instruction opcodes
and
stores them
in
the decoded instruction queue for immediate use by
the execution unit.
The memory management unit (MMU) consists of a
segmentation unit and a paging unit. Segmentation
allows the managing of the logical address space by
providing
an
extra addressing component, one that
allows easy code and data relocatability, and effi-
cient sharing. The paging mechanism operates be-
neath and is transparent to the segmentation proc-
ess,
to allow management of the physical address
space. Each segment
is
divided into one or more 4K
byte pages. To
implement a virtual memory system,
the
B03B6
supports full restartability for all page and
segment
faults.
Memory is organized into one or more variable
length
segments, each
up
to four gigabytes
in
size. A
given region of the
linear address space, a segment,
can have attributes associated with it. These
attri-
butes include its location, size, type
(Le.
stack, code
or data), and protection characteristics. Each task
on
an
B03B6
can have a maximum of
16,3B1
seg-
ments of
up
to four gigabytes each, thus providing
64
terabytes (trillion bytes) of virtual memory to each
task.
The segmentation unit provides
four-levels of pro-
tection for isolating and protecting applications and
the operating system from each other. The hardware
enforced protection
allows the design of systems
with a high degree of integrity.
The
80386 has two modes of operation: Real Ad-
dress Mode (Real Mode), and Protected Virtual Ad-
dress Mode (Protected Mode).
In
Real Mode the
B0386 operates as a very fast
80B6,
but with 32-bit
extensions if desired.
Real Mode
is
required primari-
7
Iy
to setup the processor for Protected Mode opera-
tion. Protected Mode provides access to the sophis-
ticated memory management, paging and privilege
capabilities of the processor.
Within Protected Mode, software
can
perform a task
switch to enter into tasks designated as
Virtual
B086
Mode tasks. Each such task behaves with
BOB6
se-
mantics, thus allowing
BOB6
software (an application
program, or
an
entire operating system) to execute.
The
Virtual
80B6
tasks can be isolated and protect-
ed
from one another and the host B0386 operating
system, by the use of paging,
and
the
110
Permis-
sion Bitmap.
Finally, to
facilitate high performance system hard-
ware designs, the 80386 bus interface offers ad-
dress pipelining, dynamic data
bus
sizing, and direct
Byte
Enable signals for each byte of the data bus.
These hardware features are described
fully begin-
ning
in
Section
5.
2.2 REGISTER OVERVIEW
The B0386 has 32 register resources
in
the following
categories:
o General Purpose Registers
o Segment Registers
o Instruction Pointer and Flags
o Control Registers
o System Address Registers
o Debug Registers
o Test Registers.
The registers are a superset of the
8086, 80186 and
B0286 registers, so all 16-bit 8086, B0186 and
802B6 registers are contained within the 32-bit
803B6.
Figure
2-1
shows all of B0386 base architecture reg-
isters, which include the general address and data
registers, the instruction pointer, and the
flags regis-
ter. The contents of these registers are task-specific,
so these registers are automatically
loaded with a
new context upon a task switch operation.
The base architecture
also includes six directly ac-
cessible
segments, each
up
to 4 Gbytes
in
size. The
segments are indicated
by
the selector values
placed
in
80386 segment registers
of
Figure 2-1.
Various
selector values can be loaded as a program
executes, if desired.
